FPM-721W

21.5" Full HD IndustrialMonitor with P-CAP Touch Control, Direct HDMI, DP, and VGA Ports

  • 21.5" Full HD TFT LED LCD with true-flat touchscreen
  • 16:9 wide screen aspect ratio, increases viewing area by 40%
  • Supports 10-point multi-touch control via USB interface in Windows 7/8/10 OS
  • Slim design enables easy installation
  • Supports various mount options: panel, desktop, and VESA arm
  • Touchscreen with reliable glass surface and P-CAP touch control
  • Robust system with Die-casting aluminum chassis and IP66-rated aluminum alloy front bezel
  • Lockable I/O connectors
  • Supports various mount options: panel, wall, desktop, rack or VESA arm mounting

Certifications:

Support Links:

Datasheet Download 3D Model Teknik İndirmeler
  • 21.5" Full HD IndustrialMonitor with P-CAP Touch Control, Direct HDMI, DP, and VGA Ports

Specifications

Environment
Ingress Protection
  • Front Panel IP66
  • Front Panel IP66
Operating Temperature
  • -20~60 °C (-4~140 °F)
  • -20~60 °C (-4~140 °F)
Storage Temperature
  • -30~70 °C (-22~158 °F)
  • -30~70 °C (-22~158 °F)
Storage Humidity
  • 10~95% RH (non-condensing)
  • 10~95% RH (non-condensing)
Vibration Protection
  • 1 Grms, random
  • 1 Grms, random
Hardware
Certification
  • CB, UL, CE, FCC Class A, CCC, BSMI
  • CB, UL, CE, FCC Class A, CCC, BSMI
Power Input
  • 24 VDC
  • 24 VDC
Video Port
  • HDMI, DP, VGA
  • HDMI, DP, VGA
LCD Display
Backlight Life (hrs)
  • 30,000
  • 30,000
Display Size
  • 21.5"
  • 21.5"
Luminance (cd/m2)
  • 350
  • 350
Max. Resolution
  • 1920 x 1080
  • 1920 x 1080
Viewing Angle (H/V°)
  • 178/178
  • 178/178
Mechanical
Enclosure
  • Die-cast Aluminum
  • Die-cast Aluminum
Mounting
  • Stand, Wall, VESA, Panel
  • Stand, Wall, VESA, Panel
Weight (Net)
  • 7 kg (15.4 lb)
  • 7 kg (15.4 lb)
Touchscreen
Touch Type
  • 10-point multi-touch projected capacitive
  • 10-point multi-touch projected capacitive

Accessories
