Industrial IP65 Monitor

IDS-3315

15" 1024 x 768, VGA/DVI/HDMI interface, Front IP65 Monitor

  • Front IP65 for waterproof and dustproof
  • 15" XGA LCD panel with LED backlight for 20% power saving and environmental protection
  • -20 ~ +60 °C wide range operating temperature
  • 5-wire resistive and P-cap touchscreen solution or tempered smudge resistant protected glass
  • Multiple signal interfaces with HDMI, VGA & DVI
  • Standard integrated frame
  • Versatile mounting methods for rear mounting and VESA mounting
  • Anti-Reflective treatment (optional)
  • Ultra high brightness solution of 1200 cd/m2 for outdoor applications (optional)

Certifications:

Support Links:

Datasheet Download 3D Model Technical Downloads
  • 15" 1024 x 768, VGA/DVI/HDMI interface, Front IP65 Monitor

Specifications

LCD Display
Size
  • 15"
  • 15"
  • 15"
  • 15"
  • 15"
  • 15"
Resolution
  • 1024 x 768, XGA
  • 1024 x 768, XGA
  • 1024 x 768, XGA
  • 1024 x 768, XGA
  • 1024 x 768, XGA
  • 1024 x 768, XGA
Viewing Angle (H/V°)
  • 176/176
  • 176/176
  • 176/176
  • 176/176
  • 176/176
  • 176/176
Brightness
  • 1200 nits
  • 500 nits
  • 1200 nits
  • 500 nits
  • 1200 nits
  • 500 nits
Colors
  • 262K/16.2M
  • 262K/16.7M
  • 262K/16.2M
  • 262K/16.7M
  • 262K/16.2M
  • 262K/16.7M
Contrast Ratio
  • 2000 : 1
  • 2500 : 1
  • 2000 : 1
  • 2500 : 1
  • 2000 : 1
  • 2500 : 1
Response Time (ms)
  • 23
  • 23
  • 23
  • 23
  • 23
  • 23
Backlight Type
  • LED
  • LED
  • LED
  • LED
  • LED
  • LED
Backlight Life (hrs)
  • 50,000
  • 50,000
  • 50,000
  • 50,000
  • 50,000
  • 50,000
Touch Screen
  • Tempered Glass
  • Tempered Glass
  • Projective Capacitive Touch
  • Projective Capacitive Touch
  • 5-wire Resistive touch
  • 5-wire Resistive touch
Signal Interface
  • VGA x 1; DVI-D x 1; HDMI x 1; 12VDC Jack x 1;
  • VGA x 1; DVI-D x 1; HDMI x 1; 12VDC Jack x 1;
  • VGA x 1; DVI x 1; HDMI x1; 12V DC Jack x 1; USB x 1; ( USB is reserved for the connection to enable touch usage only)
  • VGA x 1; DVI x 1; HDMI x1; 12V DC Jack x 1; USB x 1; ( USB is reserved for the connection to enable touch usage only)
  • VGA x1; DVI-D x1; HDMIx1;12 VDC Jack x1; USB x1; RS-232 x1(USB & RS-232 are reserved for the connection to enable touch only)
  • VGA x1; DVI-D x1; HDMIx1;12 VDC Jack x1; USB x1; RS-232 x1(USB & RS-232 are reserved for the connection to enable touch only)
Dimension
  • 365 x 291 x 46 mm
  • 365 x 291 x 46 mm
  • 365 x 291 x 46 mm
  • 365 x 291 x 46 mm
  • 365 x 291 x 46 mm
  • 365 x 291 x 46 mm
Weight
  • 4.5kg
  • 4.5kg
  • 4.5kg
  • 4.5kg
  • 4.5kg
  • 4.5kg
Environment
Operational Temperature
  • -20 ~ 60° C
  • -20 ~ 60° C
  • -20 ~ 60° C
  • -20 ~ 60° C
  • -20 ~ 60° C
  • -20 ~ 60° C
Storage Temperature
  • -30 ~ 70° C
  • -30 ~ 70° C
  • -30 ~ 70° C
  • -30 ~ 70° C
  • -30 ~ 70° C
  • -30 ~ 70° C
Humidity
  • 10 ~ 90% @ 40° C, non-condensing
  • 10 ~ 90% @ 40° C, non-condensing
  • 10 ~ 90% @ 40° C, non-condensing
  • 10 ~ 90% @ 40° C, non-condensing
  • 10 ~ 90% @ 40° C, non-condensing
  • 10 ~ 90% @ 40° C, non-condensing
Touchscreen
Surface Hardness
  • Mohs 5
  • Mohs 5
  • 3H
  • 3H
Durability
  • -
  • -
  • 10 million touches
  • 10 million touches
Transparency
  • 89%
  • 89%
  • 80%
  • 80%

Features & Benefits

Your Reliable Industrial Display Solution Provider

Advantech, a global leader in industrial solutions with over 15 years of expertise, specializes in reliable, high-quality edge industrial displays. Our offerings include rugged display solutions, immersive curved touch displays, and outdoor display kits, all designed to withstand harsh environments. With extensive in-house design and manufacturing capabilities, we provide highly customizable embedded solutions that cater to diverse customer needs. Our commitment to innovation ensures that our display systems not only enhance the user experience but also integrate seamlessly into various industrial applications, driving efficiency and productivity across multiple sectors.

Embedded Industrial Display Systems Industrial Display Solutions

Technology Highlights

Optical Bonding

Optical Bonding

  • Laminates LCD panels using optical glue without creating air gaps
  • Reduces external light reflection and glare by increasing backlight transmittance
  • Enhances visibility by 400% while delivering superior image quality
  • Sunlight readable, anti-moisture, anti-dust, and vandalism-resistant
Ultra High Brightness

Ultra High Brightness

  • In-house backlight module enhancement
  • Thermally optimized circuit design for low power consumption
  • Improved color saturation (NTSC) and uniformity
  • Auto-dimming function with light sensor to reduce backlighting in darker areas
  • Optional low dimming solution supporting brightness from 2 nits
Display Panel Processing

Advanced Display Enhancements

  • IP65/67-rated waterproof and dustproof solution
  • High brightness enhancement with UV-resistant and anti-reflective design
  • Supports vandal-resistant touch cover glass with customized strength
  • Anti-Glare (AG), Anti-Reflective (AR), and Anti-Fingerprint (AF) surface coatings
