EKI-5000 Series

EKI-5729FI

8GE+2G SFP Unmanaged Ethernet Switch, ATEX/C1D2, -40~75℃

  • Communicates with SCADA software via Modbus/TCP
  • Communicates with NMS (Networking management system) via SNMP
  • Port-based QoS for deterministic data transmission
  • -40~75°C operating temperature range (EKI-5729FI only)
  • 12V~48 V DC (8.4 V to 52.8 V DC ) wide-range power input
  • EMS level 3 protection for extreme outdoor environments
  • IEEE 802.3az Energy Efficient Ethernet (EEE)
  • Supports redundant 12~48V DC power input and P-Fail relay
  • Loop detection

Certifications:

Support Links:

Datasheet Download 3D Model Technical Downloads
  • 8GE+2G SFP Unmanaged Ethernet Switch, ATEX/C1D2, -40~75℃

Specifications

Certification
EMI
  • CE, FCC
EMS
  • EN 61000-4-2 (Level 3), EN 61000-4-3 (Level 3), EN 61000-4-4 (Level 3), EN 61000-4-5 (Level 3), EN 61000-4-6 (Level 3), EN 61000-4-8 (Level 3)
Safety
  • UL508, Class 1 Division 2, ATEX
Environment
Temperature (Min. Operating)
  • -40°C (-40°F)
Temperature (Max. Operating)
  • 75°C (167°F)
Operating Temperature
  • -40 ~ 75°C (-40 ~ 167°F)
Storage Temperature
  • -40 ~ 85°C (-40 ~ 185°F)
Ethernet Communication
Fiber Port Number
  • 2
Fiber Port Interface
  • SFP
Fiber Port Connector Type
  • SFP cage
Fiber Transmission Distance
  • Up to 110 km
RJ-45 Port Number
  • 8
RJ-45 Port Connector Type
  • RJ-45
RJ-45 Transmission Distance
  • 100 m
RJ-45 Transmission Speed
  • 10/100/1000 Mbps
Mechanism
Mounting (DIN-rail)
  • Yes
Mounting (Stack)
  • -
Mounting (Panel)
  • -
Mounting (Wall)
  • Yes
Mounting (Rack Mount)
  • -
Mounting (Pole Mount)
  • -
Dimensions (W x H x D)
  • 43 x 120 x 84 mm
Enclosure (Plastic)
  • -
IP Rating
  • IP30
Weight
  • 0.7 kg
PoE Information
PoE Port Number
  • -
PoE Budget
  • -
PoE Output
  • -
Support PoE
  • No
Power
Power Connector Type
  • 6-pin removable screw terminal (power & relay)
Power Consumption
  • Max. 6.8W
Power Input (DC)
  • 12 ~ 48 VDC
Power Operating Current
  • 0.23A @ 24V
Switch Properties
Jumbo Frame
  • 9,216 bytes
MAC Table Size
  • 8K
Packet Buffer Size
  • 4.1M bit
Switch Fabric Speed
  • 20Gbps
Warranty
Warranty Period
  • 5 years
Protection
Overload Current
  • Present
Reverse Polarity
  • Present

Features & Benefits


Advantech's EKI-2000 Series are the best deal offer for your Ethernet connections. Their super-slim IP30 metal casing design provides high reliability to quickly deliver continuous data transmission with high degree of security, making them an ideal option for your Ethernet solution.

Contact Us

Unmanaged Switch Plus Function Beyond Simple Connectivity

Unmanaged switch PLUS is a product concept that includes several innovative series. It introduces intelligent added features tailored for OT engineers, solving real-world challenges without IT complexity. Designed to enhance productivity, it keeps networking simple and effective in industrial environments.

LEARN MORE
High Versatile Switch Products

High Versatile Switch Products

  • Ranging from 5 to 28 ports. More than 30 skus.
  • Support din rail, wall mount or rack mount design
  • Support fast Ethernet or gigabit transmission
  • Optional fiber ports help you conquer the distance boundary
  • PoE functionality serves power and data transmission with one cable
Download Selection Guide
Plug-and-Play

Plug-and-Play

  • No setting efforts
  • No compatibility issues
  • Goes along with any network infrastructure
  • Slim size for instant installation with minimum costs and efforts, allowing users to upgrade to an intelligent plant at ease
Mini 8-cm Ethernet Switch
Robust Communication Solutions

Robust Communication Solutions

  • Super slim IP30 metal casing provides reliable & compact management
  • Support wide operating temperatures from -40 to 75oC
