UTC-115 Series

UTC-115I

15.6" All-in-One Touch Computer with 11th Gen Intel® Core™ i5/i3 Processor

  • Slimmer and Lighter design
  • Low power and fanless system design
  • Built-in Intel® Core™ i5-1145G7E
  • 15.6" monitor with 16:9 widescreen display
  • IP65-rated front panel for water and dust resistance
  • Clean back cover design with 3 Way IO cable routing
  • Supports both landscape and portrait screen orientations
  • VESA 100 mm standard mounting holes for varied mounting demands
  • Support DeviceOn- iService Suite for remote device management

Certifications:

Support Links:

Datasheet Technical Downloads
  • 15.6" All-in-One Touch Computer with 11th Gen Intel® Core™ i5/i3 Processor

Specifications

Color
Color
  • Silver
  • Silver
  • Silver
Display
Size
  • 15.6" TFT LCD
  • 15.6" TFT LCD
  • 15.6" TFT LCD
Max. Resolution
  • FHD (1920 x 1080)
  • FHD (1920 x 1080)
  • FHD (1920 x 1080)
Brightness
  • 300 cd/m²
  • 300 cd/m²
  • 300 cd/m²
Touch Screen
Type
  • Projected Capacitive
  • Projected Capacitive
  • Projected Capacitive
Processor System
CPU
  • Intel® Core™ i5-1145G7E
  • Intel® Core™ i5-1145G7E
  • Intel® Core™ i5-1145G7E
RAM
  • 8G DDR4
  • 8G DDR4
  • 8G DDR4
Storage
  • 128GB SSD
  • 256G SSD
  • 128GB SSD
OS
  • Windows 10 IoT Enterprise 64bit
  • N/A
  • Windows 11 IoT Enterprise 64bit
TPM
  • TPM 2.0
  • TPM 2.0
  • TPM 2.0
I/O Interface
Serial Port
  • 2 x COM (RS-232)
  • 2 x COM (RS-232)
  • 2 x COM (RS-232)
USB Port
  • 3 x USB 3.2 Gen1 Type-A, 1 x USB 3.2 Gen 1 Type-C, 1 x DC-in USB Type-C
  • 3 x USB 3.2 Gen1 Type-A, 1 x USB 3.2 Gen 1 Type-C, 1 x DC-in USB Type-C
  • 3 x USB 3.2 Gen1 Type-A, 1 x USB 3.2 Gen 1 Type-C, 1 x DC-in USB Type-C
Output
  • 1 x HDMI 1.4
  • 1 x HDMI 1.4
  • 1 x HDMI 1.4
Audio
  • 1 x Audio Phone Jack
  • 1 x Audio Phone Jack
  • 1 x Audio Phone Jack
Ethernet
  • 2 x Gigabit Ethernet ports
  • 2 x Gigabit Ethernet ports
  • 2 x Gigabit Ethernet ports
Speaker
  • 2 x 2W Speaker
  • 2 x 2W Speaker
  • 2 x 2W Speaker
Extendable Slot
  • 1 x M.2 key2230, 1 x M.2 key2242
  • 1 x M.2 key2230, 1 x M.2 key2280
  • 1 x M.2 key2230, 1 x M.2 key2242
Peripheral
Bluetooth
  • Bluetooth® 5.3
  • Bluetooth® 5.3
  • Bluetooth® 5.3
WLAN
  • IEEE 802.11ax
  • IEEE 802.11ax
  • IEEE 802.11ax
Environment
Operating Temperature
  • 0 ~ 40 °C (32 ~ 104 °F)
  • 0 ~ 40 °C (32 ~ 104 °F)
  • 0 ~ 40 °C (32 ~ 104 °F)
Operating Humidity
  • 10 ~ 95% @ 40°C non-condensing
  • 10 ~ 95% @ 40°C non-condensing
  • 10 ~ 95% @ 40°C non-condensing
Vibration
  • 0.5G
  • 0.5G
  • 0.5G
Shock
  • 10G peak acceleration (11 msec. duration)
  • 10G peak acceleration (11 msec. duration)
  • 10G peak acceleration (11 msec. duration)
System Protection
  • IP 65 Compliant
  • IP 65 Compliant
  • IP 65 Compliant
Power
Input Rating
  • 20V/4.5A (90W)
  • 20V/4.5A (90W)
  • 20V/4.5A (90W)

Accessories
